The SW2325 fast charge protocol chip of Zhuhai Zhirong Technology Co., LTD has successfully passed UFCS 1.0
Oct 17, 2022| The SW2325 fast charge protocol chip of Zhuhai Zhirong Technology Co., LTD has successfully passed UFCS 1.0, certificate No. 0302247161601R0M-UFCS00011. Output 5V/10V/20V programmable fusion fast charging function certification, become the first batch of protocol chip products to pass this certification.
Zhirong SW2325 is a fast charge protocol controller with strong compatibility. It has a 40MHz ARM M0 core and a 64K eFlash+4K RAM. Supports an ultra-wide input voltage range of 3-30V. Support optocoupler feedback, FB feedback and I2C feedback three voltage regulation modes, and support I2C/UART universal peripheral interface, support secondary development.
Zhilong SW2325 adopts QFN-20 4X4mm package and integrates Type-C interface logic, USB PD PHY, VOOC/SCP PHY, QC/PE/SFCP/TCN and other fast charge protocol detection circuits. The optical coupling feedback and FB feedback driver circuit, NMOS and PMOS driver circuit and CV/CC control loop are integrated.
Zhirong SW2325 supports multiple protection functions, dynamic power allocation and firmware encryption, powerful and comprehensive, suitable for car charging, charger and other applications. With ACDC or DCDC and a small number of peripheral components, a complete high-performance Type-C/Type-A port fast charging solution can be formed.
